DL435 LED Downlight
This LED square surface-mounted downlight features a slim and sleek design. It is adopted high lumen 2835 SMD light source, the PC diffuser provides a uniform light output. The integrated iron plate design not only enhances the structural integrity of the downlight but also provides effective heat management. By efficiently dissipating heat, it helps to prolong the lifespan of the LED components and maintain optimal performance.
- High lumen efficiency
- Installation: Surface mount
- protection level: IP20& IK03
- Internal flicker free driver
- Easy installation and maintenance
Application Areas: It is suitable for general lighting applications , such as offices, shopping mall, hotel, restaurant, hospital, home lighting etc.
Specification FilesIES & LDT Files
| Code | DL435-300-24W |
|---|---|
| Dimension(mm) | Ø300*45 |
| Watt(W) | 24W |
| Rated Input Voltage | AC230V |
| Input Voltage | AC220-240V |
| Light Source | SMD |
| SDCM | <6 |
| CCT(K) | 1-CCT: 3000K/4000K/5000K/5700K |
| Non-DIM 1-CCT Luminous Flux (lm) ±5% CRI80 | 2500-2750 |
| CRI | 80 |
| Beam Angle (°) | 100° |
| LED Driver | Driver built-in |
| Electrical Class | Class I |
| Ingress Protection(IP Rating) | IP20 |
| Impact Resistance(IK Rating) | IK03 |
| Product Finishing | White RAL9016 |
| Optics Material | PC |
| Housing Material | Metal |
| Lifetime (hr) | 50,000h |
| Glow wire test (°C) | 750°C |
| Operating Temp.(°C) | -20°C~45°C |
| Storage Temp.(°C) | -20°C~65°C |
| Installation | Surface mount |
